Suitable for running AC powered pumps up to 0.75HP
|
Recommended MPPT voltage range
|
80 ~350V DC input for 110V/160V/220V pumps, 0.75kw
150~400VDC for 220VAC/240V pumps with 0.75Kw to 4kw 250~800VDC, for 380VAC pumps with1.5kw to 160kw |
|
Recommended input voltage
|
170Vmp DC for 110V AC pumps. 260Vmp DC for 160V AC pumps
350Vmp DC for 220V AC pumps, 620Vmp DC for 380V AC pumps |
|
Motor type
|
Control for permanent magnet synchronous motor and asynchronous motor pumps
|
|
Maximum DC power input
|
1. 450VDC for 220AC output 2. 800VDC for 380V AC output
|
|
Rated output voltage
|
1 phase, 110V/160V/220V. 3 phase, 220V/380V/480V
|
|
Output frequency range
|
0~50/60Hz
|
|
MPPT efficiency
|
99%
|
|
Ambient temperature range
|
-10~+50˚C
|
|
Solar pump control special performance
|
MPPT ( maximum power point tracking), CVT (constant voltage tracking), auto/manual operation, dry run protection, low stop frequency protection, minimum power input, motor maximum current protection, flow calculating, energy generated calculating and water tank level detected, etc.
|
|
Protection function
|
Stall protection, phase loss protection, phase short circuit protection , ground to phase short circuit protection , input and output short circuit protection, over-temperature protection, etc.
|
|
Protection degree
|
IP20, Air force cooling
|
|
Running mode
|
MPPT or CVT
|
|
Altitude
|
Below 1000m; above 1000m, derated 1% for every additional 100m.
|
